Handle Sewage Suction Tanker Truck is an advanced, reliable, and high-capacity vehicle designed for wastewater suction, sewage cleaning, and sludge transportation. Built on a strong base chassis, this tanker truck offers exceptional performance, efficiency, and durability—ideal for municipal sanitation, industrial waste management, and environmental cleaning operations.
Technical Specifications
- Base Chassis: Heavy-duty truck chassis
- Overall Size (mm): 7450 × 2400 × 3250
- Wheelbase (mm): 3800
- Gearbox: Fast 8-speed manual transmission
- Tank Capacity: 9.46 m³
- Tank Material: Q235B carbon steel
- Tank Wall Thickness: >6 mm
- Suction Range: ≥8 m
- Maximum Speed: 120 km/h
- Power: 165 HP
- Drive Type: 4×2
- Tire Specification: 8.25R20
- Tank Dimensions (mm): 5000 × 1800
- Gross Vehicle Mass (G.V.M): 14060 kg
- Vacuum Duration: ≤15 min
- Offload Duration: ≤8 min
Performance and Design
This sewage suction truck is engineered for high suction power, fast offloading, and smooth operation. The tanker’s cylindrical body is constructed from 6mm-thick Q235 high-quality carbon steel, ensuring long-lasting strength and resistance to corrosion. The tank head is formed through one-time die-casting, enhancing durability and sealing performance.
The hydraulic lifting system allows easy dumping of sludge and waste through the hydraulically opened rear cover. With automatic welding technology, the tank maintains perfect sealing performance, preventing leakage and ensuring environmental safety.
Hydraulic and Pump System
Equipped with a high-performance water circulation pump, the truck can handle heavy-duty suction and cleaning operations with ease. The high-pressure pump delivers up to 22Mpa pressure and 215 flow, ideal for unclogging drains, pipelines, and septic tanks.
The hydraulic reel includes an 80m high-pressure hose, supported by a reliable hydraulic control system for precise operation. The truck also includes:
- One 100mm sewage suction port (rear)
- One 150mm sewage discharge port
- One 100mm side suction port
- 10-meter sewage suction pipe
- 10 small dredging nozzles or 1 large mine nozzle
Optional slurry pump system allows for dry and wet separation, and an automatic alarm stops the pump when the tank is full—ensuring safe, efficient, and reliable performance.
Comfort and Operation
The driver’s cabin is built for comfort and control, featuring:
- Power steering
- Cruise control
- ABS braking system
- Clutch booster
- Air conditioning
- Central locking system
- Electric windows
- Ergonomic seat design
These features ensure safe driving, reduced operator fatigue, and enhanced maneuverability, even during extended operations.
Applications
The Sewage Suction Tanker Truck is ideal for:
- Urban sanitation and drainage cleaning
- Septic tank and sludge removal
- Industrial waste management
- Emergency sewage suction and transport
- Pipeline dredging and maintenance
Key Features (SEO Keywords)
sewage suction tanker truck, vacuum sewage truck, wastewater suction vehicle, sludge suction truck, septic tank cleaner, vacuum tanker, waste management vehicle, high-pressure cleaning truck, municipal sanitation truck, hydraulic sewage suction, Q235 steel tank, 9.46m³ sewage truck, suction range 8m, durable waste tanker, environmental cleaning vehicle.
Conclusion
This high-performance sewage suction tanker truck combines powerful suction capacity, durable construction, and modern comfort features to deliver efficient and reliable waste management solutions. Its advanced hydraulic system, heavy-duty tank design, and quick operation make it the perfect choice for municipalities, contractors, and industrial cleaning services looking for dependable and long-lasting performance.
