Pressure Boosting Water System In fire safety systems, maintaining the required water pressure is not just important—it’s mandatory. Many properties, especially in urban environments, struggle with inconsistent or inadequate pressure from town mains, which can render fire sprinkler systems non-compliant with fire safety codes. Pressure check, a highly engineered pressure boosting water system from Rightway internationals offers a compact, pr-configured, and fully compliant solution.
Whether you’re replacing a traditional pump and tank system or installing a new fire protection solution, Pressure check ensures your sprinkler system performs to the highest standards, with minimal space requirements and fast installation.
What is Pressure check?
Pressure check is a compact water supply and pressure boosting system designed to restore or maintain the minimum operating pressure for fire sprinkler systems. It occupies only about 3.5 x 3.5 meters of floor space, roughly equivalent to two car parking spaces, and stands at around 3 meters in height, depending on configuration.
Unlike bulky pump and tank solutions, Pressure check connects directly to the town-mains water supply, drawing water efficiently and boosting pressure only when needed. This allows building owners and developers to save space, reduce costs, and streamline fire protection installations.
How Pressure check Works
Under normal conditions, the sprinkler system is fed directly from the town-mains (indicated by the blue route). Water flows through a Reduced Pressure Zone (RPZ) and supplies the sprinkler network.
If the mains pressure drops below the required level, the system automatically switches to the red route. Here’s what happens:
- Pump Activation: The internal pump activates and draws water from the AVC (Anti Vacuum Chamber).
- Chamber Refill: The AVC is replenished by the town mains via high-capacity float valves.
- Pressure Maintenance: The system maintains optimal operating pressure for consistent fire sprinkler performance.
This intelligent switching system ensures that your sprinkler pressure remains compliant with fire codes at all times, even during drops in town mains pressure.
Key Features of Pressure-check
- ✅ Plug-and-Play Design: Fully assembled, pre-wired, and tested at the factory.
- ✅ Quick Installation: Minimal on-site assembly reduces downtime and installation costs.
- ✅ Compact Footprint: Fits within a 3.5×3.5 metre area, preserving valuable building space.
- ✅ Hazard Classification Ready: Available in OH1, OH2, and OH3 hazard ratings.
- ✅ Pump Options: Equipped with fire pumps rated for 15m, 30m, or 45m depending on the height of the highest sprinkler head.
- ✅ Factory Tested: All systems are pressure tested and performance verified before shipment.
- ✅ Custom-Built: Pr-configured to match your building’s requirements for pressure, flow rate, and fire risk classification.
Benefits Over Traditional Pump and Tank Systems
- Space Efficiency: Replaces large tanks and pump rooms with a self-contained, compact system.
- Revenue Space Recovery: Frees up space that can be used for other revenue-generating functions.
- Lower Installation Costs: Pre tested and modular design means quicker and cheaper installations.
- Reliable Performance: Maintains correct system pressure even during mains failure.
- Regulatory Compliance: Ensures your sprinkler system meets fire safety regulations without compromise.
Applications of Pressure check
Pressure check is ideal for:
- Commercial buildings with limited plant room space
- Retrofit projects where tank installation is impractical
- Properties experiencing low or fluctuating town-mains pressure
- High-rise buildings with elevated sprinkler heads
- Facilities requiring OH1, OH2, or OH3 hazard protection levels
Why Choose Rightway Internationals Pressure check?
we prioritize engineering excellence, safety compliance, and installation efficiency. Every Pressure check unit is:
- Manufactured in-house with strict quality control
- Supplied with all relevant documentation and certifications
- Delivered ready for plug-and-play installation
- Backed by expert technical support
Documentation and Compliance
Each Pressure-check system comes complete with comprehensive project documentation, including:
- Quality Assurance Plans
- Factory Acceptance Test Reports
- Engineering Drawings and Schematics
- Compliance Certificates (NFPA, LPCB, EN12845, etc.)
- User Manuals and Maintenance Guidelines
Conclusion
Pressure check is the future of compact, compliant, and cost-effective fire sprinkler pressure boosting systems. With minimal space requirements, pre tested reliability, and seamless integration into existing water supply systems, it’s the ideal alternative to traditional pump and tank systems.
