Sewage Suction Vacuum Truck is an essential vehicle for modern sanitation and municipal waste management operations. Designed to collect, transport, and dispose of sludge, sewage, and liquid waste, these trucks ensure efficient suction and discharge while preventing secondary pollution. Whether for urban sanitation, construction sites, industrial waste, or municipal sewage systems, these trucks are engineered for performance, capacity, and durability.
What Is a Sewage Suction Truck?
A sewage suction truck, also known as a vacuum suction truck, is a specialized vehicle equipped with a vacuum pump and storage tank. It is used to suck up and transport sludge, mud, sewage, and other liquid or semi-solid waste materials. The truck supports self-suction and self-discharge functions, significantly improving operational efficiency and reducing the risk of contamination.
Key Features and Benefits
✅ High-Capacity Waste Handling
With a tank volume ranging from 6,000L to 10,000L, the truck can handle large waste loads in a single trip. This reduces downtime and improves overall productivity, especially in high-demand environments like city waste management, rural sanitation, or industrial waste collection.
✅ Powerful Vacuum Pump System
Equipped with a domestically developed vacuum pump, the truck delivers:
- Strong suction power
- Long suction range
- Capability to handle thick sludge, stones, silt, bricks, and more
Perfect for challenging waste environments, including clogged drainage systems or construction sludge.
✅ Rapid Operation & Easy Transportation
Designed for fast suction, loading, and discharging, the truck helps minimize time on-site. Its compact body and powerful engine also make it ideal for navigating both urban and off-road conditions.
Technical Specifications
| Model | CLW5071GXW3 |
|---|---|
| Tank Volume | 6,000L – 10,000L |
| Total Weight | 7,360 kg |
| Curb Weight | 3,230 kg |
| Dimensions (L×W×H) | 5510×1990×2500 mm |
| Number of Axles | 3 |
| Wheelbase | 3,300 mm |
| Tire Size | 7.00R16 |
| Transmission | 5-Speed Manual |
| Front/Rear Axle Load | 1.8T / 3.5T |
| Brake System | Air Brake |
| Fuel Type | Diesel |
| Emission Standard | Euro 3 |
| Engine Model | CY4100Q |
| Displacement | 3,767 ml |
| Power Output | 130 kW / 95 HP |
| Maximum Speed | 95 km/h |
| Suction Pipe Length | 10 meters |
Standard Equipment
- Hydraulic lifting tank with tilt unloading capability
- Hydraulic rear cover opening for easy discharge
- 6-meter suction pipe (x1 included)
- Self-flow port for gravity-based drainage
- Oil-water separator for safe operation
- Safety valve to prevent overpressure or backflow
Applications
Sewage suction trucks are widely used in:
- Urban and rural municipal sanitation
- Septic tank cleaning and maintenance
- Construction sites for removing sludge and debris
- Industrial waste suction and disposal
- Flooded area drainage and sludge removal
- Crude oil and hazardous liquid transportation
Conclusion
The sewage suction vacuum truck is a powerful and reliable solution for handling all types of liquid and semi-solid waste. With its robust suction system, large tank capacity, and advanced hydraulic features, this vehicle is indispensable for modern waste management tasks. Whether you’re managing urban infrastructure or handling industrial waste, this truck provides safe, fast,
